Sku's 90MB18X0-M0EAY0 Ean's 4711081523017 Processor Socket
Max aantal processors
Chipsettype
Producttype
Compatibele processoren
- (ondersteunt 12e generatie Intel Core / Pentium Gold / Celeron)
LAN Netwerk interfaces
Audio Conformiteitsnormen
Type
- 7.1-Channel High Definition Audio
Ondersteund RAM Ondersteunde RAM-integriteitscontrole
- Niet-ECC, ECC (werkt in non-ECC-modus)
Geregistreerd of Gebufferd
Maximale grootte
Technologie
Busklok
- 2400 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3400 MHz (O.C.), 3333 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 4000 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4600 MHz (O.C.), 4800 MHz (O.C.), 3200 MHz, 5000 MHz (O.C.), 5066 MHz (O.C.)
Functies
- Dubbelkanaals geheugenarchitectuur, Intel Extreme Memory Profiles (XMP)
Processor / chipset Chipsettype
Uitbreiding / Aansluiting Stroomconnectoren
- 24-pins hoofdstroomconnector, 8-pins ATX12V connector
Uitbreidingssleuven
- 1 x CPU
- 4 x DIMM 288-pins
- 1 x PCIe 4.0 x16
- 1 x PCIe 3.0 x16 (x4-modus)
- 2 x PCIe 3.0 x1
- 1 x M.2 socket (Key E)
Storage Interfaces
- SATA-600 -aansluitingen: 4 x 7-pins seriële ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5
- PCIe 4.0 -aansluitingen: 3 x M.2
RAID-functies
- Intel Rapid Storage Technology
Interfaces
- 1 x HDMI
- 1 x DisplayPort
- 1 x VGA
- 1 x LAN (2.5Gigabit Ethernet)
- 1 x USB-C Gen2x2
- 2 x USB 2.0
- 2 x USB 3.2 Gen 2
- 1 x USB 3.2 Gen 1
- 1 x microfoon - ministekker
- 1 x audiolijningang - ministekker
- 1 x audiolijnuitgang - ministekker
Interne interfaces
- 4 x USB 2.0 - header
- 2 x USB 3.2 Gen 1 - header
- 1 x USB-C Gen 1 - header
- 1 x audio - header
- 1 x serieel - header
- 1 x Thunderbolt - header
- 1 x SPDIF-uitgang - header
Garantie van de fabrikant Service & Support
- Beperkte garantie - 3 jaar
Diversen Conformiteitsnormen
Diepte
Breedte
Meegeleverde accessoires
- I/O-achterplaat, 3 x M.2 schroeven, 1 x M.2 rubber verpakking
Kabels meegeleverd
Software meegeleverd
- Stuurprogramma's & hulpprogramma's, ASUS CPU-Z, WinRAR, Norton AntiVirus (proefversie), ASUS AURA Creator
Functies BIOS-type
BIOS-functies
- UEFI BIOS, ASUS EZ Flash 3
Slapen/ontwaken
- Activering op LAN (wake on LAN = WOL), wake on PME
Hardwarefuncties
- Taakverandering van de stekerbus, ASUS Q-Design, ESD Guards, ASUS TurboV EVO, Q-DIMM, ASUS EZ DIY, Q-Slot, CrashFree BIOS 3, audiojack detectietechnologie, ASUS EPU (Energy Processing Unit), Intel Turbo Boost-technologie 2.0, ASUS DIGI+ VRM, bescherming tegen te hoge stroomsterkte voor verbeterde DRAM van ASUS, Preboot eXecution Environment (PXE), ASUS Stainless Steel Back I/O, ASUS Fan Xpert 2+, LANGuard, ASUS-overspanningsbescherming, Intel Optane Memory Ready, ASUS 5X Protection III, Intel Turbo Boost Max Technology 3.0, ASUS OptiMem, ASUS Aura Sync, Armoury Crate, ASUS SafeSlot Core+
